Винты с цилиндрической головкой
Описание:
Марка стали: 10 кп; 10; 10 пс
Класс точности: В
Поле допуска резьбы винтов: бg
| d | 3 | 4 | 5 | 6 | 8 | 10 |
|---|---|---|---|---|---|---|
| D | 5,5 | 7,0 | 8,5 | 10,0 | 13,0 | 16,0 |
| к | 2,0 | 2,6 | 3,3 | 3,9 | 5,0 | 6,0 |
| b | 12,0 | 14,0 | 16,0 | 18,0 | 22,0 | 26,0 |
| L | 6-30 | 6-40 | 10-50 | 10-60 | 16-60 | 20-70 |
| L,mm | Масса 1000 штук винтов, кг | |||||
|---|---|---|---|---|---|---|
| 6 | 0,600 | 1,175 | - | - | - | - |
| 7 | 0,643 | 1,251 | - | - | - | - |
| 8 | 0,687 | 1,328 | ||||
| 9 | 0,730 | 1,404 | - | - | - | - |
| 10 | 0,773 | 1,481 | 2,567 | 3,918 | - | - |
| 11 | 0,816 | 1,557 | 2,689 | 4,093 | - | - |
| 12 | 0,860 | 1,634 | 2,811 | 4,267 | - | - |
| 13 | 0,903 | 1,710 | 2,933 | 4,442 | - | - |
| 14 | 0,946 | 1,786 | 3,056 | 4,617 | - | - |
| 16 | 1,033 | 1,932 | 3,300 | 4,966 | 9,777 | - |
| 18 | 1,120 | 2,092 | 3,544 | 5,315 | 10,408 | - |
| 20 | 1,206 | 2,245 | 3,789 | 5,664 | 11,040 | 18,58 |
| 22 | 1,293 | 2,398 | 4,033 | 6,014 | 11,670 | 19,58 |
| 25 | 1,423 | 2,627 | 4,400 | 6,537 | 12,617 | 21,08 |
| 28 | 1,553 | 2,857 | 4,766 | 7,061 | 13,563 | 22,57 |
| 30 | 1,640 | 3,010 | 5,011 | 7,411 | 14,194 | 23,57 |
| 32 | - | 3,162 | 5,255 | 7,760 | 14,824 | 24,57 |
| 35 | - | 3,392 | 5,622 | 8,284 | 15,771 | 26,06 |
| 38 | - | 3,621 | 5,988 | 8,808 | 16,717 | 27,56 |
| 40 | - | 3,774 | 6,232 | 9,157 | 17,348 | 28,56 |
| 42 | - | - | 6,477 | 9,506 | 17,979 | 29,55 |
| 45 | - | - | 6,844 | 10,031 | 18,925 | 31,05 |
| 48 | - | - | 7,210 | 10,554 | 19,872 | 32,55 |
| 50 | - | - | 7,454 | 10,904 | 20,503 | 33,54 |
| 55 | - | - | - | 11,777 | 22,080 | 36,04 |
| 60 | - | - | - | 12,650 | 23,657 | 38,53 |
| 65 | - | - | - | - | - | 41,02 |
| 70 | - | - | - | - | 43,52 | |
